TH146-N-2H1C
TH146-N-2H1C Honeywell - Low volt Non-programmable 1 heat/1 cool conventional and 2 heat/1 cool heat pump thermostat; 2 - 6 CPH; Power Method Hardwired
Availability: In stock
$744.93
Details
Details
TH146-N-2H1C Honeywell
The TH146-N-2H1C Honeywell is a thermostat that features a 2-wire user console connection, idea for retrofits. This TH164-N-DE includes a non-programmable console, a control module, and an outdoor temperature sensor.
| Application | Heat/Cool or Heat Pump with Auxiliary Heat |
| Dimensions | User console: 3.1 in. X 3.1 in. X 1 in.; Control module: 3 in. X 4.3 in. X 1 in. Control module: 76 mm X 109 mm X 25 mm; User Console: 79 mm X 79 mm X 24 mm |
| Includes | CT280-2H1C control module, TH146 user console, AC144-03 Outdoor Temperature Sensor (3-m/10-ft) with Mounting Clip |
| Used With | Controllers; Aube AC130-12 wallplate; Aube AC146-410 Air Duct; Temperature Probe; Aube CT240/CT241 Telephone |
| Comments | Two-piece Design: Two-wire User Console Connection, Dual-Energy Input, Backlight, Remote Input for Telephone Controller |
| Mounting | Control Module: Horizontal; User console: Vertical |
| Stages | Up to 1 Heat/1 Cool Conventional; Up to 2 Heat/1 Cool Heat Pump |
| Operating Humidity Range (% RH) | 0 to 90% RH, non-condensing |
| Supply Voltage | Maximum load per output: 1 A @ 24 VAC; Power supply: 24 VAC |
| Switch Positions (System) | HEAT-OFF-COOL-AUTO-EM.HEAT |
| Switch Positions (Fan) | AUTO/ON |
| Operating Temperature Range | 32 F to 122 F 0 C to 50 C |
| Sensor Element | Thermistor |
| Accuracy | ±1 F ± 0.5 C |
| Color | White |
| Ambient Temperature Range | -58 F to 158 F -50 C to 70 C |
| Switch Type | Relay |
| LEDs | Console: System Fault, Em. Heat, Dual-energy; Module: 1 per output |
| Power Method | Hardwired |
| Terminal Designations | R, C, W, Y, G, (O/B), WW, L |
| Changeover | Auto/Manual Selectable |
| Setting Temperature Range | 40 F to 86 F 5 C to 30 C |
| Cycles per Hour | 2-6 CPH (Heating and Cooling) |
| Cool Current | 1.0 A |
| Heat Current | 1.0 A |
| Fan Current | 1.0 A |
| Fan Operation | On/Auto |
Additional Info
Additional Info
| Name | TH146-N-2H1C |
|---|---|
| Documentation | No |
| Manufacturer | Honeywell |
| UPC: | TH146-N-2H1C Honeywell |
