CTS-20-250-VFD-001
4-20ma Adj Current Sensing Relay
In Stock (1)
Availability: In stock
$83.99
Details
Details
Overview
Depending on the model, current is converted into a linear and proportional output signal of 0-5 Vdc, 0-10 Vdc or 4-20 mA and monitored by a building management controller. These Fast acting current sensors are reliable and extremely easy to install.
Features
- Solid or split core loop-powered current transmitters for 4-20 mA models
- Solid or split core 0-5 or 0-10 Vdc models
- Fast response time
- Integral DIN rail mounting flange
- Easy wiring, polarity sensitive output
- Accepts up to a 350 MCM (17.3 mm) cable
- Operates up to 250 continuous amps
- True RMS versions are available
- RoHS and WEEE Complaint
- Limited 5 Year Warranty.
Product Specifications
| Application | Excellent choice for new installations requiring load treading (current monitoring) |
| Dimensions (in.) | 2 17/64 in. high x 3 3/8 in. wide x 63/64 in. deep |
| Dimensions (mm) | 58 mm high x 86 mm wide x 25 mm deep |
| Weight <lb) | 0.22 lb |
| Weight (kg) | 0.1kg |
| Frequency | 30 Hz to 1 kHz |
| Approvals, Underwriters Laboratories Inc. | Approved |
| Operating Humidity Range (% RH) | 0 to 95% RH, non-condensing |
| Supply Voltage | 12 to 30 Vdc |
| Operating Temperature Range (F) | 5 F to 104 F |
| Operating Temperature Range (C) | -15 C to 40 C |
| Approvals, CE | Approved |
| Enclosure | UL94-5V/Burgundy |
| Type | Adjustable |
| Accuracy | ±0.5% |
| Core Type | Solid |
| Supply Current | 36 mA max |
| Maximum Current | continuous--160 Amps; 320 Amps; 400 Amps: for 6 seconds--200 Amps; 400 Amps; 500 Amps; |
| Jumper Settings | Low; Middle; High |
| Output Switch Rating | 4-20 mA Average True RMS |
| Isolation Voltage | 2200 Vac |
| Maximum Load Resistance | 650 Ohms @ 24 Vdc (Vs-10)/0.02-40.2 |
| Response Time | <200 mS |
| Aperture Size | 3/4 in. (19 mm). Accepts up to 350 MCM (17.3 mm) cables. |
| Approvals, Environmental Compliance | RoHS-Directive 2002/95/EC, WEEE-Directive 2002/96/EC |
| Current Ratings | 0-200 Amps; 0-250 Amps; 0-100 Amps |
| DIN Rail Size (in.) | 1-3/8 in. |
| DIN Rail Size (mm) | 35 mm |
Additional Info
Additional Info
| Name | CTS-20-250-VFD-001 |
|---|---|
| Documentation | N/A |
| Manufacturer | Honeywell |
| UPC: | CTS-20-250-VFD-001 Honeywell |
