EL11310

EL11310 Baldor-Reliance 1 HP General Purpose Motor

The Baldor-Reliance EL11310 is a durable 1 horsepower single-phase AC motor designed for general-purpose commercial and industrial applications. Built with a NEMA 56 frame and an open drip-proof (ODP) enclosure, this motor provides dependable performance for equipment installed in clean, dry indoor environments.

The EL11310 operates on 115/230 VAC, single-phase, 60 Hz power and delivers approximately 1750 RPM rated operating speed. Its capacitor-start, capacitor-run design provides strong starting performance along with reliable operation for applications requiring continuous or frequent-duty service.

Constructed with a rugged steel frame and rigid foot mounting, the EL11310 is suitable for a wide range of equipment including fans, blowers, pumps, conveyors, machine tools, and other general-purpose motor-driven equipment.

EL11310 Features

• Manufacturer: Baldor-Reliance / ABB
• Part Number: EL11310
• Motor Type: General Purpose AC Motor
• Horsepower: 1 HP
• Phase: Single Phase
• Voltage: 115/230 VAC
• Frequency: 60 Hz
• Rated Speed: Approximately 1750 RPM
• Synchronous Speed: 1800 RPM
• NEMA Frame: 56
• Enclosure: Open Drip-Proof (ODP)
• Mounting: Rigid Foot Mount
• Motor Design: Capacitor Start / Capacitor Run
• Service Factor: 1.15
• Insulation Class: Class F
• Frame Material: Steel
• Duty: Continuous Duty
• Shaft Diameter: 5/8 in.

Applications

The EL11310 Baldor motor is well suited for replacement and OEM applications involving fans, blowers, pumps, material-handling equipment, machinery, and other equipment requiring a dependable 1 HP, 115/230V single-phase motor.

Always verify the motor horsepower, voltage, phase, frame size, shaft dimensions, mounting configuration, rotation requirements, and electrical specifications before ordering to confirm compatibility with your equipment.
