TH108PLUS
TH108PLUS Honeywell - Non-Programmable Line Volt manual thermostat with TRIAC for electric heat; 240 Vac, 60 Hz; Two or Four Wire; 41 - 86F.
REPLACES: TH108
In Stock (6)
Availability: In stock
$57.04
Details
Details
TH108PLUS Honeywell
The TH108PLUS Honeywell with TRIAC switching is a digital thermostat that delivers exceptional accuracy and silent operation in a stylish, easy-to-use design.
| Application | Convector; Electric Heating; Baseboard heater; Radiant ceiling |
| Dimensions | 4.8 in. X 4.5 in. X 1 in. 120 mm X 115 mm X26 mm |
| Comments | battery-free; Backlight, On-screen heating power indicator; Works on 240 VAC only |
| Mounting | Vertical |
| Electrical Rating | Min. load: 2 A (resistive only), 500 W @ 240 VAC; Max. load: 12.5 A (resistive only), 3000 W @ 240 VAC |
| Frequency | 50 Hz; 60 Hz |
| Electrical Connections | 6 in. (150 mm) tinned copper lead wires |
| Supply Voltage | 240 Vac |
| Switch Positions (System) | °C/°F |
| Sensor Element | Thermistor |
| Accuracy | 0.27 F 0.15 C |
| Color | White |
| Ambient Temperature Range | 32 F to 122 F 0 C to 50 C |
| Switching Action | SPST |
| Switch Type | Triac |
| Power Method | Hardwired |
| Setting Temperature Range | 40 F to 85 F 5 C to 30 C |
Additional Info
Additional Info
| Name | TH108PLUS |
|---|---|
| Documentation | N/A |
| Manufacturer | Honeywell |
| UPC: | TH108PLUS Honeywell |
