TH135-01-B

TH135-01-B Honeywell - Non-Programmable Low volt non-programmable heat-only thermostat for central heating; 1 Heat, Heat Only; 3 to 4 CPH; 24 Vac or 24 Vdc; Power Method 2 AA alkaline batteries; Mounting Vertical.

In stock

SKU
TH135-01-B
Availability
In-Stock (2)
$82.87
Details

TH135-01-B Honeywell

The TH135-01-B Honeywell is an easy-to-use electronic thermostat saves three temperature settings and is millivolt compatible.

TH135-01-B Specifications
Application                                                     Heat Only
Dimensions 3.1 in. X 3.1 in. X 0.8 in.
79 mm X 79 mm X 22 mm
Comments Comfort, Economy and Vacation Presets; packed in box; Pump protection for hot water heating; Remote input for telephone controller
Mounting Vertical
Stages 1 Heat
Operating Humidity Range (% RH) 0 to 90% RH, non-condensing
Supply Voltage 24 Vac or 24 Vdc
Operating Temperature Range 32 F to 122 F
0 C to 50 C
Sensor Element Thermistor
Accuracy ±1 F
± 0.5 C
Color White
Switch Type Relay
Power Method 2 AA alkaline batteries
Terminal Designations R, W, (X, C, optional remote input)
Setting Temperature Range 40 F to 85 F
5 C to 30 C
Cycles per Hour 3 or 4 CPH
Heat Current 5 A (Resistive) 2 A (Inductive)



Additional Info
Manufacturer Honeywell
