VBN3CJPX7400
VBN3CJPX7400 Honeywell
1 inch, 3-way female NPT threaded Actuated Control Ball Valve with 8.6Cv capability; SR, 2-position, 24 vac actuator, Plated Brass Trim; 360 psig
REPLACES: VBN3CJ3P0C, VB3CABC
Call For Availability
Availability: In stock
$407.01
Details
Details
VBN3CJPX7400 Honeywell
Control Ball Valve Female Threaded 24V 3-Way 1" NPT (DN25) 8.6Cv Plated Brass Trim
| Maximum Safe Operating Pressure | 360 psi 2482 kPa |
| Enclosure |
None |
| Connection Type | Female NPT |
| Body Pattern | Three-way |
| Pipe Size | 1 in. DN25 |
| Fluid Temperature | -30 C to +121 C -22 F to +250 F |
| Maximum Differential Pressure Ratings (Close-off) | 50 psi 345 kPa |
| Capacity | 8.6 Cv 7.4 kvs |
| Valve Type | Control Ball Valve |
| Controlled Fluid | Chilled or hot water with up to 50% Glycol. Not for use with steam or fuels. |
| Materials (Body) | |
| Materials (Seat) | |
| Materials (Stem) | |
| Flow Characteristic | Equal Percentage (A-AB); Linear (B-AB) |
| Actuation | Spring Return Two Position, 24 Vac |
| Materials (Plug/Ball/Disc) | Nickel-plated brass ball |
| Materials (Flow Control Insert) | |
| Leakage | ANSI Class IV (0.01% of Cv maximum) |
Additional Info
Additional Info
| Name | VBN3CJPX7400 |
|---|---|
| Manufacturer | Honeywell |
| UPC: | VBN3CJPX7400 Honeywell |
